A&D ML-50 Moisture Analyser

Test With The BEST – Quick, Safe And Accurate

A&D’s straight halogen lamp, uniquely designed SRA (Secondary Radiation Assist) filter gives shorter measurement time, thanks to fast and uniform heating. With SHS (Super Hybrid Sensor) featured as the weight sensor, ultra accurate moisture content determination is possible based on high precision weighing of even a small sample. The ergonomically designed pan handle eliminates mishaps when moving a hot sample tray. Standard features include 5 measurement modes, Data Memory function, RS-232C interface, Sodium Tartrate Dihydrate and with a easy-to-see, large VFD display. GLP Compliant. The MX-50 comes with WinCT-Moisture CD-ROM, sample pans (x20), pan handles (x2), tweezers, spoon, test sample (30g of Sodium Tartrate Dihydrate), glass fibre sheet, RS-232C cable, display cover and dust cover

Quick & Easy Measurements
4 Selectable heating modes from standard, quick, step and ramp that help customize heating curves to your unique sample types for accuracy & precision.

5 Selectable measurement programs to best fit sample and process with STANDARD, QUICK, AUTOMATIC, TIMER, MANUAL
Clear & easy-to-view with the large VFD display means setting values, change in moisture content, action status indicators, and data number are clearly visible.

Safe & Reliable Design
Easy handles & ergonomic design helps to prevent burn injuries while improving workflow movements of samples in and out efficiently

Self Check functions such as defect check function along with temperature control checks have you covered

Progress window allows easy visibility to see heating process through translucent window

Quick Reference Card for convenient operating guide is installed at the bottom of the analyser

Compliant & Traceable Reporting
Data Interface is a breeze with RS-232C interface and our WinCT–Moisture software that helps determine measurement conditions as well as optimize time & accuracy

Data memory function allows for test results to be stored and recalled or outputted for additional analysis

GLP, GMP, GCP and ISO compliant with date/time, ID, calibration data and check record outputs

Fast and uniform heating with halogen lamp and innovative SRA technology

Straight halogen lamp and uniquely designed SRA (Secondary Radiation Assist) filter gives shorter

measurement time, thanks to fast and uniform heating

High Repeatability
With SHS (Super Hybrid Sensor) featured as the weight sensor, ultra accurate moisture content determination is possible based on high precision weighing of even a small sample

High moisture content measurement
ML-50 measures the moisture content at 0.1% resolution suitable for mid-low moisture content samples as well as Karl Fischer method, yet requires no special knowledge or training and produces no harmful waste.  Standard WinCT-Moisture (for MS&MX) for real-time graph displaying.

WinCT-Moisture is an original software application designed to display a graph of moisture content rate change while measuring with a connected PC.

Sodium Tartrate Dihydrate comes as standard for accuracy checking
Sodium Tartrate Dihydrate is a chemical material that has stable moisture content of 15.66% and thus is best to use for accuracy check to maintain the reference value of the analyser.

Calibration of the heater temperature (for MS&MX)
With the temperature calibrator (optional), calibration result can be output in the format that conforms to GLP, GMP, ISO.

Memory function
According to sample up to 20 suitable measurement conditions can be stored and recalled, which saves time and prevents the user from making a mistake when setting (10 for MF
5 for ML)  For measurement result, up to 100 data can be stored and output at once (50 for MF
30 for ML)

Five measurement programs
Ergonomically designed pan handle eliminates mishaps such as burns when moving a hot sample pan into or out of the unit from either side. Wing handle for easy opening and closing of the heater cover.

Low maintenance cost assured
The halogen lamp is user replaceable without unit downtime with protective chamber for easy cleaning (Lamp life 5000 hours).

Heating Technology: Halogen Lamp, 400 Watt

Capacity / Readability / Moisture Content Display: 51g / 0.001g / 0.01%/0.1%

Drying Temperature: 50 – 200°C

Measurement Mode: Moisture Content (Wet or Dry Base) / Dry Content / Ratio / Weight (g)

Measurement Programs: Standard Mode, Automatic Mode, Quick Mode, Timer Mode, Manual Mode

Interface: RS-232C (cable supplied)

Power Supply: AC 100V to 120V (3A) or AC 200V to 240V (1.5A), 50/60 Hz, Approx. 400W
