Description
Robust, Functional And High Performing Pallet Trucks
Pallet truck scales, with built-in electronic weighing, for dangerous areas classified as hazardous (zones 1 and 21 & 2 and 22) in accordance with Ex II 2G IIB T4 Gb X and Ex II 2D IIIC T197°C Db X
The Atex certified four load cell weight detection IP68 guarantees the best accuracy in all work conditions
Main Features:
Maximum lifting capacity: 2500 kg
Accuracy: +/- 0.05% of the maximum capacity
Fork dimensions 1150 x 550 x 85 mm
Weighs about 125 kg
Bearing structure in extra thick sheet steel and oven-fire painted interior construction
Standard fitted with +/-160° swivelling column head
Steering wheels and double loading rollers with a poliurethane coating
Atex certified, 4 stainless steel IP68 shear-beam load cells
Indicator with easy to clean satin finish stainless steel case with IP68 enclosure built to withstand humid and dusty environments; large LCD display 25-mm high contrast digits which are clearly visible even in poor lighting conditions; 17-key numerical/functional membrane waterproof keyboard
Calibration and Set-Up parameters configurable from keyboard
Power supply through extractable battery, rechargeable in safe zone
150-hour approximate operating time
Equipped with 230Vac 50 Hz battery charger to be recharged in a safe area
WARNING:
With ATEX weighing systems, when directly weighing light metals (such as aluminum, magnesium, titanium and their alloys), it is necessary to use the STAINLESS STEEL loading forks
Applications: High Resolution Weighing x 10, Net/Gross or lb/kg Conversion, Weighs Accumulation, Formula Weighing, Hold, Piece Counting
Weighing Units: kg, lb
Power Supply: Power supply 230Vac 50 Hz battery charger to be recharged in a safe area
