A Strong, Reliable And Affordable Stainless Steel Drive Thru Scale
The DTS range of drive through scales is designed and manufactured in Leicester by MWS. Its main feature is a low profile weighing deck for easier and safer loading by operators. Its design enables us to ensure that the unit is strong enough to cope with loads up to 2000kg yet remain less than 50mm high.
The DTS is manufactured in 304 grade stainless steel (316L available upon request) and is suitable for use in areas where there is an abundance of moisture. It is fitted with IP68 load cells and junction box as standard, making the DTS a truly waterproof floor scale built for the rigours of the food and chemical industry.
A glass bead blast top and bottom is used to finish, which is hygienic for a majority of applications. However, upon request a grained or electro polish finish can improve the surface finish.
- Designed for easy weighing of dolavs, racks and trolleys in manufacturing industries
- The DTS is a compact low profile scale – it takes up the minimum of floor space
- The main fabrication structure is folded from a single piece of stainless steel for extra strength and total flatness
- Lifting handles double as ramp guides for trolleys
The OHAUS next generation Defender 5000 Series multi-functional indicator is ideal for use in conjunction with bench and floor scales for a multitude of applications including production, packaging, inventory and shipping. Built durably and equipped with advanced features such as maximum configurability print output, GMP/GLP data output, library/user management and multiple connectivity options – the Defender 5000 Series is designed to handle demanding industrial and commercial applications.
Multi-functional Indicator for Standard Industrial Applications
The OHAUS next generation Defender 5000 Series multi-functional indicator is ideal for use in conjunction with bench and floor scales for a multitude of applications including production, packaging, inventory, and shipping. Built durably and equipped with advanced features such as maximum configurability print output, GMP/GLP data output, library/user management, and multiple connectivity options – the Defender 5000 Series is designed to handle demanding industrial and commercial applications.
•Indicator Guides The User with On-Screen Prompts
See results clearly on the large backlit display. The alpha-numeric keypad and function keys allow for a simplified user experience. On-screen prompts and soft keys will guide you through the operation.
•Multiple Connectivity Options for Convenient Data Transfer and Storage
Results can be stored in the Micro SD card. Data output via built-in RS232 or optional interfaces including RS232/RS485/USB device, USB Host, Ethernet and Bluetooth/WiFi, Analog Output and Discrete I/O with relays.
•Multiple Application Modes and High Storage Capacity for Greater Flexibility
Features common industrial modes and supports a 50,000 item library and 1,000 user profiles which can be downloaded/uploaded for easy set-up (with SD Card.) Also equipped with GMP/GLP capability with time/date for result traceability.
•Install Easily with the ‘EasyConnect’ Feature
When connecting to Defender 5000 bases, the EasyConnect™ technology allows instant connection and use of the scale without extra configuration.
|Battery Life||20 Hours with Rechargeable Battery|
|Outputs||4 – 20mA; 2 In/4 Out digital I/O|
|Second Scale Input||Not applicable|
|Communication||Ethernet (Available as an Accessory); 2nd RS232/RS485/USB (available as an accessory); RS232 (Included); USB Host (Available as an Accessory); WiFi/Bluetooth (available as an accessory)|
|Dimensions||10.6 in x 8.7 in x 3 in (270 mm x 222 mm x 76 mm) (LxHxW)|
|Display||Dot matrix LCD with white LED backlight|
|Legal for Trade||EC Type Approvable; OIML|
|Net Weight||4.4 lb (2 kg)|
|Power||Rechargeable Battery (Not Included); AC Power (Included)|
|Tare Range||To capacity by subtraction|
|Units of Measurement||Metric Tons; Gram; Kilogram; Pound; Tonne; Custom; Ounce; Pound:Ounce|
|Working Environment||14°F – 104°F, 85%RH, non-condensing (-10°C – 40°C, 85%RH, non-condensing)|
